Modern rear wheel drive cars with independent rear suspension typically use cv joints at the ends of the rear axle halfshafts and. Download cv joint guide series 30 934 930 cv boots.
Gkn Driveline
Tripod cv joint design. A clever new constant velocity cv joint is smaller and lighter freeing up room for space constrained automotive designers. Rzeppa undercut free tripod anti shudder tripod cross groove double offset. 2a and 2b illustrate weak portions in the tripod joint which should be considered in the joint design in order to provide a tripod constant velocity joint having a desirable strength in terms of a torsional strength and a durability or torsional fatigue in particularin the tripod joint design the shortest or minimum diameter sd of shaft 5 is typically considered to be the weakest. State of the art cae cv joint design. Tripod plunging gi joint. The computer aided design cad files and all associated content posted to this website are created.
September 29th 2014. Constant velocity joints also known as homokinetic or cv joints allow a drive shaft to transmit power through a variable angle at constant rotational speed without an appreciable increase in friction or playthey are mainly used in front wheel drive vehicles. The vl3 cv joint currently being used on the side shaft of independent rear suspensions on the bmw 5 series and 7 series luxury vehicles is said to deliver 27 more torque with no increase in packaging size. Tripod housings fsae items are only available direct through rcv performance at msrp. In this research an instrumented advanced cv joint friction tester was developed to measure the internal friction behavior of cv joints using actual tripod type joint assemblies. This joint is not a true constant velocity joint since the medium plane always lies perpendicular to the axis of the drive shaft.
The standard tripod joint gi is suitable for the inboard gearbox joint of a constant velocity sideshaft for most vehicles. September 29th 2014 tripod jointstep. In addition to the properties of the standard tripod joint the low plunging resistance and low axial forces of the aar joint delivers additional nvh noise vibration hardness refinement making it appropriate for high working angles. It is ideal for medium working angles and its low plunge resistance aids good nvh characteristics. 50 degrees outboard 28 degrees inboard. It has a maximum articulation angle of 23 degrees and has a plunge length of 50mm.
The setup is capable of measuring key performance parameters such as friction and wear under different realistic operating conditions of oscillatory speeds and cv joint installation angles. Silicone neoprene high temperature thermoplastic. Tripod plunging aar joint angular adjusted roller. Tripot joint tripod ball cv joint hartford technologies bearing specialists collaborate with prominent automotive and off road vehicle tier 1 companies to design and manufacture production volumes of tripot joint components.
